Acoustic emission valve leak detector with 16-bit sampling accuracy that can be set to 200 different valves
Up to 200 different valves can be set, and each valve can store up to 8 calibration curves.
Small size and light weight, convenient to carry and operate；Standard USB interface, strong versatility；Battery compartment screw lock, safe and reliable.
| Model Number |
SVLD1 |
| Sampling frequency optional |
4MHz/2MHz/1MHz/500KHz/200KHz/ 100KHz/50KHz/20KHz |
| Sampling precision |
16bit |
| Protection level host |
Host:IP64,Sensor:IP66 |
| Channel quantity |
1 |
| Working temperature |
-10℃-50℃ |
| Working humidity |
20%~90%RH |
| Analog filter |
Six kinds of filters can choose(1MHz-1MHz,1MHz-600MHz,20KHz-1MHz,20KHz-600KHz,100KHz-1MHz,100KHz-600KHz) |
| power supply |
3VDC(Two AA alkaline batteries) |
| Display screen |
128*64 dot matrix LCD |
| Dimensions |
136(L)*72(W)*20(H)mm |
| Weight |
176g(With battery) |
| Number of valves |
200 |
| Generate parameters |
RMS,ASL,P |
Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.
We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.
Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).
Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.
