SVLD1 Acoustic Emission Valve Leak Detector To Inspect Valve Leaks
| Place of Origin | GUANGDONG |
|---|---|
| Brand Name | AE |
| Certification | CE,CQM |
| Model Number | SVDL1 |
| Minimum Order Quantity | 1 set |
| Price | 500 USD |
| Packaging Details | 1 pcs/plastic handheld bag ,carton for outside packing |
| Delivery Time | 5-20 work days |
| Payment Terms | T/T |
| Supply Ability | 30 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | SVDL1 Valve Leakage Detector | Generate Parameters | RMS,ASL,P |
|---|---|---|---|
| Display Screen | 128*64 Dot Matrix LCD | Response Frequency | 1kHz-1MHz (±1.5dB) |
| Protection Level Host | IP64 | Channel Quantity | 1 |
| Dimensions | 136(L)*72(W)*20(H)mm | Number Of Valves | 200 |
| High Light | Acoustic Emission Valve Leak Detector,SVLD1 Acoustic Emission Detector,IP64 Valve Leak Detector |
||
Product Description
SVLD1 Acoustic Emission Valve Leakage Detector to Inspect Valve Leaks
- Product description
○ Communication interface: High-speed USB interface provides data export, which can be processed on the host computer.
○ Working mode: It can provide valve acoustic emission parameter test and valve leakage test (in the calibrated state);
○ Daily valve leakage detection can be completed by operating panel function keys, which is simple and intuitive and easy to learn, without entering the menu operation.
| Model Number | SVLD1 |
| Sampling frequency optional | 4MHz/2MHz/1MHz/500KHz/200KHz/ 100KHz/50KHz/20KHz |
| Sampling precision | 16bit |
| Response frequency | 1kHz-1MHz (±1.5dB) |
| Protection level host | Host:IP64,Sensor:IP66 |
| Channel quantity | 1 |
| Working temperature | -10℃-50℃ |
| Working humidity | 20%~90%RH |
| Built-in preamplifier | 26dB (Sensor) |
| Analog filter | Six kinds of filters can choose(1MHz-1MHz,1MHz-600MHz,20KHz-1MHz,20KHz-600KHz,100KHz-1MHz,100KHz-600KHz) |
| Weight | 176g(With battery) |
| storage | 50000 sets of test data |
| power supply | 3VDC(Two AA alkaline batteries) |
-
