Handheld Acoustic Emission Valve Leak Detector 4MHz 2MHz 1MHz
| Place of Origin | GUANGDONG |
|---|---|
| Brand Name | AE |
| Certification | CE,CQM |
| Model Number | SVDL1 |
| Minimum Order Quantity | 1 set |
| Price | 500 USD |
| Packaging Details | 1 pcs/plastic handheld bag ,carton for outside packing |
| Delivery Time | 15 work days |
| Payment Terms | T/T |
| Supply Ability | 30 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | SVDL1 Valve Leakage Detector | Product Name | Acoustic Emission Valve Leakage Detector |
|---|---|---|---|
| Sampling Precision | 16bit | Response Frequency | 1kHz-1MHz (±1.5dB) |
| Protection Level Host | IP64 | Dimensions | 136(L)*72(W)*20(H)mm |
| Working Temperature | -10℃-50℃ | Storage | 50000 Sets Of Test Data |
| High Light | Valve Leak Detector 4MHz,Handheld Detector 2MHz,Valve Leak Detector 1MHz |
||
Product Description
SVDL1 Handheld Acoustic Emission Valve Leakage Detector
- Product description
1.Apply the principles of acoustic emission technology, simplify operation process, easy to operate,setting plural keyboard shortcuts, can finish leakage detect ion with only one button;
2.Choose AE time indicators(RMS,ASL,P) as leakage testing parameters, thus can demarcate the valve leakage rate.Once leakage rate is demarcated,the detector can display the referential values while testing.
| Model Number | SVLD1 |
| Sampling frequency optional | 4MHz/2MHz/1MHz/500KHz/200KHz/ 100KHz/50KHz/20KHz |
| Protection level host | Host:IP64,Sensor:IP66 |
| Channel quantity | 1 |
| Working temperature | -10℃-50℃ |
| Working humidity | 20%~90%RH |
| Built-in preamplifier | 26dB (Sensor) |
| Analog filter | Six kinds of filters can choose(1MHz-1MHz,1MHz-600MHz,20KHz-1MHz,20KHz-600KHz,100KHz-1MHz,100KHz-600KHz) |
| power supply | 3VDC(Two AA alkaline batteries) |
| Display screen | 128*64 dot matrix LCD |
| Weight | 176g(With battery) |
| Number of valves | 200 |
| Generate parameters | RMS,ASL,P |
-
Company Introduction
Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.
We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.
Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).
Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.
- Certifications
- FAQ
Q:What is the price term?
A: FOB Shanghai /Guangzhou/ Shenzhen
Q: Are your company a trading one or a factory?
A: We are a group company with 5 factories in Shanghai, Jiangsu and Guangdong. Our company has a professional foreign trade sales team and an experienced technical support team. We are an intelligent equipment & automation solution integration service provider.
Q:How to deal with the faulty part if exceeds the warranty time?
A:Customer can return the faulty parts for our testing and maintaining, all the logistic fee should be at customer’s cost.
If you have any other questions please feel free to contact us.
