SUB100 Ultrasonic Flaw Detection Equipment USB 2.0 Interface
| Place of Origin | Guangdong |
|---|---|
| Brand Name | AE |
| Certification | CE、CQM |
| Model Number | SUB100 |
| Minimum Order Quantity | 1Piece |
| Price | 2300 USD |
| Packaging Details | Carton-box |
| Delivery Time | 10 days |
| Payment Terms | T/T |
| Supply Ability | 30 Piece/pieces per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | SUB100 Digital Ultrasonic Flaw Detector | Size | 230*170*55(mm) |
|---|---|---|---|
| Display | 5.7 Inch TFT Color Screen | Weight | 1.56kg |
| Application | Used In Power Engineering, Automatic Machinery And Equipment, Etc. | Function | Used To Detect, Locate, Evaluate And Diagnose Various Injuries |
| Warranty | 1 Year | Brand | AE |
| High Light | SUB100 ultrasonic flaw detection equipment,NDT Testing Equipment USB 2.0 Interface,1.56kg ultrasonic flaw detection equipment |
||
Product Description
SUB100 Ultrasonic Flaw Detector with 5.7 Inch TFT LCD Display Instrument USB 2.0 Interface
Detailed introduction
Non-destructive testing of internal defects such as pores. It is widely used in electric power engineering, boiler pressure vessel, steel structure, military industry, aviation, railway transportation, automatic mechanical equipment and other industries. It is an indispensable testing tool in the field of non-destructive testing.
| Key technical indicators | |||
| Item | Indicator | Item | Indicator |
| Testing scope | 0~9999mm | linear inhibition | 0~80%(digital suppression) |
| Working frequency | 0.2MHz~15MHz | Vertical linear error | ≤3% |
| Sound velocity | 1000m/s~9999m/s | Horizontal linear error | ≤0.1% |
| Gain Coverage | 0dB~110dB | Dynamic Scope | ≥32dB |
| Sampling rate | 100MHz | Battery | 6*3.7V(lithium battery) |
| Display delay | -20μs~+3400μs | Electricity | 8.4V |
| Probe zero -offset | 0μs~99.99μs | Ambient Temperature | -20°C~50°C |
| Level of electrical noise | ≤10% | ambient humidity | 20%~90%RH |
| Surplus sensitivity | >63dB | size | 23cm*17cm*5.5cm |
| Resolution Ratio | >40dB(5P14) | Weight | 1.56KGS(including leather case) |
Standard Configuration:
| No. | Description | Model | Qty. |
| 1 | Detector(with wristlet) | SUB100 | 1 |
| 2 | Charger | CD20L02QF | 1 |
| 3 | Connecting cable | 1M | 2 |
| 4 | Normal probe | F20mm,2.5MHz | 1 |
| 5 | Angle probe | 13′13k2,2.5MHz | 1 |
| 6 | SUFD3 operating manual | English Manual | 1 |
| 7 | PC software | Support Windows XP | 1 |
| 8 | USB Disk | 2G | 1 |
Company Information
Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.
We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.
Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).
Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.
FAQ
1.What is the price term?
FOB Shanghai.
2.What’s the warranty time?
12 months after shipment date
3.What’s the delivery date?
10-30 days after receiving the T/T payment.
4.How to place order?
Talk to service staff, confirm machine details, and then place order.
5.Whether the OEM and ODM is avaliable?
Yes, it is.
Our advantage:
Strictly implementing the ISO9001 international quality system standard, we have established a complete quality system certification. Satisfy users with high-quality services and reasonable prices. Product development is based on relevant national industry standards and aims to meet the needs of the future development vision of the power system. Provide various high-tech power testing products for national power systems, metallurgy, petrochemicals, factories, and institutions. Products have been widely used in electric power, coal, petroleum, chemical, metallurgy, construction, railway, communications, national defense and other sectors, and are well received by customers.
Our services:
Pre-Sales Service:
* Inquiry and consulting support.
After-Sales Service:
* Training how to install the machine, training how to use and maintain the machine.
