| Model Number |
SW7 |
| Measurement Range |
0.65mm~500mm |
| Working temperature |
-10~+50°C(Room temperature measuring environment) |
| Display accuracy |
0.01mm/0.001inch |
| Material sound velocity |
509m/s~18699m/s |
| Measurement accuracy |
±(0.5%H+0.03)mm |
| Reception bandwidth |
1MHz~10MHz(-3dB) |
| Measurement frequency |
2~20 times/second(can set up optionally) |
| Power |
3VDC(two pieces of AA alkaline batteries) |
| Working time |
280 hours(automatic mode)100 hours(Backlight opens) |
| Display screen |
128*64 lattice LCD |
| Surface test range |
Upper limit-Φ15mm*1.0mm(Probe:7.5MHz,Φ6mm) |
| Lower limit-Φ10mm*1.2mm(Probe:7.5MHz,Φ6mm) |
| Dimensions |
136(L)*72(W)*20(H)mm |
| Weight |
176g(With battery) |
| Working humidity |
20%~90%RH |
| Built-in test block thickness |
3mm |
Main Features
·This gauge can measure a variety of materials, including metals, plastics, rubber, ceramics, composites, epoxy resins, glass and other materials with good ultrasonic conductivity.
·It can be equipped with a variety of probes and thickness gauge to meet different thickness measurement applications, including coarse-grained materials such as gray cast iron and high-temperature environmental measurement (up to 300 ℃)
·Multiple measurement modes
·The special curved surface measurement mode is suitable for pipe wall thickness measurement to improve the accuracy of curved surface thickness measurement
Company information
Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.
We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.
Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).
Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.
Certifications
FAQ
1.What is the price term?
FOB Shanghai.
2.What’s the warranty time?
12 months after shipment date
3.What’s the delivery date?
7- 25 days after receiving the T/T payment.
4.How to deal with the faulty part if exceeds the warranty time?
Customer can return the faulty parts for our testing and maintaining
