SCAL2 Acoustic Emission Testing Equipment Handheld Acoustic Emission Calibrator
| Place of Origin | GUANGDONG |
|---|---|
| Brand Name | AE |
| Certification | CE,CQM |
| Model Number | SCAL2 |
| Minimum Order Quantity | 1 set |
| Price | Negotiable |
| Packaging Details | carton box |
| Delivery Time | 10 work days |
| Payment Terms | T/T |
| Supply Ability | 30 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | SCAL2 Handheld Acoustic Emission Calibrator | Power | Electronic |
|---|---|---|---|
| Screen Type/Resolution Ratio | Colorful /320 X 240 | Accuracy Range | ±0.3 DB |
| Frequency Range | ±0.5% | Protection Level Of Outside Shell | IP65 |
| Continuous Baterry Charging Time | No Less Than 10 H | Connecter Type | BNC |
| High Light | SCAL2 Acoustic Emission Testing Equipment,AE Acoustic Emission Testing Equipment SCAL2,SCAL2 handheld calibrator |
||
Product Description
SCAL2 Acoustic Emission Testing Equipment Handheld Acoustic Emission Calibrator
- product description
Settable variables :signal waveform,signal amplitude,signal frequency, emission speed,gain,threshold;Signal waveform: AE double exponential envelope, AE triangular envelope,impulse sine wave ,continuous sine wave,signal impulse wave;AE parametric indicators: rise time,duration time,ring-down count;After boot initialization, the system can automatically turn out the configuration which was set before closing.
| Model Number | SCAL2 |
| Precision | Range of amplitude fluctuation:±0.3dB |
| Frequency fluctuation range:±0.5% | |
| Signal amplitude of the sine wave | 30dB-100dB |
| Signal amplitude of the AE waveform | 30-90dB |
| Signal frequency of the continuous sine wave | 10kHz~1MHz,0.1kHz stepping adjustable |
| Signal frequency of AE waveform | 30kHz,60kHz,150kHz,300kHz |
| Emission seed | 1pps,10pps,100pps,1000pps,manual controlled |
| Preamplifier gain | 0dB,26dB,40dB |
| Protection level of outside shell | IP65 |
| Continuous Baterry charging time | no less than 10h |
| Connecter type | BNC |
| Working temperature | 0~40℃ |
| Storage temperature | -20~60℃ |
| Relative humidity | 30~90% |
| Antivibration level | GB/T 242310.2008 or other equivalent standard |
- Company Profile
Shanghai Liangui Technology Co., Ltd. is committed to promoting the prosperity and development of the world through technology, focusing on Intelligent Equipment & Automation Solutions to to help enterprises to improve production process and minimize the cost.
We are an intelligent equipment & automation solution integration service provider. Our company has a professional foreign trade sales team and an experienced technical support team, the principles of our team work is customer first and fast solution. Our business scope includes NDT Testing Equipment, Acoustic Emission Testing Instruments, Industrial Robot, Mechanical and Electrical Equipment etc.
Our NDT testing division is specialized in the R & D, production, sales and technical application services of Acoustic Emission Testing Instruments, Ultrasonic Flaw Detector, Ultrasonic Thickness Gauge and other Testing Instruments. Our R&D team has the ability to develop Sensors, Electronic Measurement Software and Hardware, we can also customize Non-standard Automated and Robotic Inspection Equipment for customers. Our products mainly used in Industrial Field (Aerospace, Railway, Automotive, Oil & Gas, Manufacturing, Process Industry ) and Power Generation (Renewable, Nuclear, New Reactors, Advanced Reactors, Research Reactors, Gas Combined, Coal, Cogeneration).
Our objective is to always help our clients meet their high safety standards, proposing efficient inspection solutions based on global services which reduce costs and increase process efficiency, make industrial facilities and power generation to operate safely, efficiently and excellently. Our major products AE system and instruments have been sold to China, USA, UK, Brazil, Indonesia and so on, which win the trust and support of customers from all over the world with an excellent reputation.
- FAQ
Q: Are your company a trading one or a factory?
A: We are a group company with 5 factories in Shanghai, Jiangsu and Guangdong. Our company has a professional foreign trade sales team and an experienced technical support team. We are an intelligent equipment & automation solution integration service provider.
Q:What is the price term?
A:FOB Shanghai.
Q:What’s the warranty time?
A:12 months after shipment date.
Q:How to place order?
A:Talk to service staff, confirm machine details, and then place order.
