Acoustic Emission System
>
SCAL2 Acoustic Emission Calibrator

SCAL2 Acoustic Emission Calibrator

Product Details:
Place of Origin: CHINA
Brand Name: QingCheng AE
Certification: CE,CQM
Model Number: SCAL2
Detail Information
Place of Origin:
CHINA
Brand Name:
QingCheng AE
Certification:
CE,CQM
Model Number:
SCAL2
Name:
SCAL2 Acoustic Emission Calibrator
Acoustic Emission Waveform Signal Amplitude:
30-90dB
Accuracy Range:
±0.3dB
Frequency Range:
±0.5%
Working Temperature:
0~40℃
Storage Temperature:
-20~60℃
Relative Humidity: 30~90%:
30~90%
Antivibration Level:
GB/T 242310.2008 Or Other Equivalent Standard
Highlight:

High Light

Highlight:

Acoustic Emission Handheld Calibrator

,

SCAL2 ndt testing equipment

,

AE SCAL2 Handheld Calibrator

Trading Information
Minimum Order Quantity:
1 Piece
Price:
Negotiable
Packaging Details:
Outside packing Size(L*W*H mm):450*350*160 Packing way: 1pcs/leather sheath handheld bag ,plastic bag per unit,carton for outside packing
Delivery Time:
10 days
Payment Terms:
T/T
Supply Ability:
30 Piece/pieces per month
Product Description



SCAL2 Handheld AE Calibrator





Designed and developed for the requirements of acoustic emission detector calibration. It can export various standard



parametric signals like amplitude, rise time, counts and duration. SCAL2 is suitable for calibration of availability of AE



detector, AE sensors and preamplifier before using them, and it is suitable for detecting the working condition of



acoustic wave (acoustic emission) detection system in a local environment. The design of SCAL2 is based on.



It also can be used as a standard signal generator.







Functional parameter





►Settable parameters: Waveform type, Amplitude, Frequency, Signal transmission rate, gain, threshold





►Signal waveform: AE double exponential envelope, AE triangular envelope, Impulse sine wave,



    Continuous sine wave, Signal impulse wave





►Signal amplitude of the sine wave: 30dB-100dB





►Signal amplitude of the AE waveform: 30dB-90dB





►Signal frequency of the continuous sine wave: 10kHz~1MHz





►Signal frequency of AE waveform: 30kHz, 60kHz, 150kHz, 300kHz





►AE characteristic parameter: Rise time, Duration, Counts





►Signal transmission rate: 1pps,10pps,100pps,1000pps,manual control





►Preamplifier gain: 0dB,26dB,40dB





►Accuracy: range of amplitude ±0.3dB, frequency range ±0.5%











Physical parameters





►Protection grade: IP65





►Battery powered and more than 10h of independent continuous working time





►Connector type: BNC





►Working temperature: 0~40℃





►Avoid external electromagnetic interference





►Prevent vibration can meet GB/T 242310.2008 standard (or other equivalent standard)





►Colorful screen, resolution ratio 320 x 240
